Behringer continues to expand its XENYX line of analog mixers with the launch of the 1002SFX and 1202SFX models, hot on the heels of the 502S and 802S.
As the model numbers suggest, these are 10 and 12 inputs respectively. As expected, they seamlessly connect to a computer via USB. Two mono channels with EQ and Low Cut, plus 4 stereo channels, a stereo RCA streaming input and stereo USB input allow you to blend a total of 14 audio signals for streaming, monitoring via headphones or on high-quality TRS outputs. The mixer delivers crystal-clear audio for high-quality streaming, plus it comes with an amazing Klark Teknik FX processor with a hundred presets to add that extra spice to your mix.
Controls include level, panorama/balance, and effect send on all channels allowing for precise sound shaping of input sources. Mono channels have additional Gain controls and 3-band EQ with switchable Low Cut, while stereo line-level channels offer a switchable 12 dB boost.
The FX send control per channel lets you use the internal stereo effects programs and/or plug in any external FX processor for additional audio effects flexibility.
Specifications
The specifications are as follows:
Mono Inputs
Microphone Input
Balanced XLR, discrete input circuit
Mic EIN (22 Hz-22 kHz) @ 50 ?: 132 dB, A-weighted
Frequency response Gain +10 dB: 10 Hz to 150 kHz
Frequency response Gain +60 dB: 20 Hz to 70 kHz
Gain range: +10 dB to +60 dB
Max input level @ +10 dB Gain: +12 dBu
Input Impedance 2 k? balanced
Distortion (THD + N) 1 kHz
@ +10 dB Gain: 0.005%
Mono Line Inputs
1/4″ TRS connector balanced
Impedance: 22 k? Balanced, 10 k? unbalanced
Gain range: -10 dB to +40 dB
Max input level @ 0 dB Gain: +21 dBu
Stereo Inputs
Stereo Line
1/4″ TRS connector balanced
Frequency response: 20 Hz to 200 kHz
Impedance: 22 k? Balanced, 10 k? unbalanced
Max input level @ 0 dB Gain: +21 dBu
STREAM Inputs (Analog)
RCA connector unbalanced
Impedance: 10 k? unbalanced
Max input level: 10 dBu
EQUALIZER
Low: 80 Hz/±15 dB
Mid: 2.5 kHz/±15 dB
High: 12 kHz/±15 dB
Main, Monitor & FX Send Outputs
Type: 1/4″ TRS connector impedance-balanced
Impedance: 120 ?
Max output level: 21 dBu
Phones Out
Type: 1/4″ TRS connector unbalanced
Impedance: 23 ?
Max output level: 19 dBu/150 ?
STREAM out (Analog)
Type: RCA connector unbalanced
Impedance: 1 k? unbalanced
Max output level: 10 dBu
Main Mix noise
Main Mix @ -?
-108 dBu A-weighted
Channel @ -?
-108 dBu A-weighted
FX Section
Type: Klark Teknik
Converter: 24-bit Sigma Delta
Sample Rate: 40 kHz
USB
Type: Type-B connector
USB Audio Data: 48 kHz 16 Bit
UAC2 Class Compliant: stereo in/out
Available now, pricing to be confirmed. Product pages: XENYX 1002SFX / XENYX 1202SFX
